Codice modello

Cornice

Corrente in ingresso (A)

Corrente di uscita (A)

Motore tipico (W)

Dimensioneeee

Unità di frenatura

10 HP

30 CV

10 HP

30 CV

Altezza (H)

Larghezza (L)

Profondità(D)

Resistenza massima (Ω)

Resistenza minima (Ω)

Potenza del resistore di frenatura (W)

W1-L-AJ-B-2002

9.2

5.2

9.6

1.1/2.2

347,0 mm

223,0 mm

143,0 mm

145.0/72.0

125,0/65,0

300/600

Integrato

W1-L-AJ-B-2003

7.5

1,5/3,7

347,0 mm

223,0 mm

143,0 mm

105/54.0

90,0/50,0

450/1100

220-NV-L-A/B-4007

17.9

20.5

10.3

22/4.0

347,0 mm

223,0 mm

173,5 mm

72.0/40.0

63.0/35.0

600/1200

220-NV-L-A/B-4011

25.3

15.5

3.7/5.5

347,0 mm

223,0 mm

173,5 mm

43.0/29.0

37.0/25.0

1100/1600

220-NV-L-A/B-4015

31.3

4.0/7.5

347,0 mm

223,0 mm

173,5 mm

40.0/26.0

35.0/22.0

1200/2500

220-NV-L-A/B-4018

34.6

22.5

5.5/11.0

350,0 mm

210,0 mm

188,0 mm

29.0/14.5

25.0/13.0

1600/3500

220-NV-L-A/B-4022

42.6

27.5

11.0/15.0

360,0 mm

210,0 mm

188,0 mm

18.0/13.0

16.0/12.5

3500/4500

220-NV-L-A/B-4030

52.6

34.6

15.0/18.5

554,5 mm

289,6 mm

223,0 mm

13.0/12.5

13.0/12.0

4500/5500

Codice modello	Cornice	Corrente in ingresso (A)	Corrente di uscita (A)	Motore tipico (chilowatt)	Dimensioneeee			Dimensioneeee			Unità di frenatura
		30Ph	30Ph		Dimensioneeee			Dimensioneeee
		30Ph	30Ph		Altezza (H)	Larghezza (L)	Profondità(D)	Resistenza massima (Ω)	Resistenza minima (Ω)	Potenza del resistore di frenatura (W)
NV-L-A/B-4002	C	6.5	5.1	2.2	347,0 mm	223,0 mm	143,0 mm	290	230	600	Integrato
NV-L-A/B-4003	C	10.5	9	3.7	347,0 mm	223,0 mm	143,0 mm	170	135	1100
NV-L-A/B-4005	C	14.8	13	5.5	347,0 mm	223,0 mm	143,0 mm	115	90	1600
NV-L-A/B-4007	D	20.5	18	7.5	347,0 mm	223,0 mm	173,5 mm	85	65	2500
NV-L-A/B-4011	D	29	27	11	347,0 mm	223,0 mm	173,5 mm	55	43	3500
NV-L-A/B-4015	D	36	33	15	347,0 mm	223,0 mm	173,5 mm	43	35	4500
NV-L-A/B-4018	E	41	39	18.5	350,0 mm	210,0 mm	188,0 mm	34	25	5500
NV-L-A/B-4022	E	49.5	48	22	350,0 mm	210,0 mm	188,0 mm	24	22	6500
NV-L-A/B-4030	E	62	60	30	554,5 mm	289,6 mm	223,0 mm	20	16	9000
NV-L-A/B-4037	F	77	75	37	549,0 mm	385,0 mm	265,0 mm	16	13	11000	Esterno
NV-L-A/B-4045	F	93	91	45	549,0 mm	385,0 mm	265,0 mm	14	11	13500	Esterno

Codice modello	Potenza nominale (kVA)	Corrente di uscita nominale (A)	Potenza motore adatta (kW)	Codice modello	Potenza nominale (kVA)	Corrente di uscita nominale (A)	Potenza motore adatta (kW)
Invertitore 200V				Invertitore 400V
2S01P1	2.3	6	1.1	4T01P1	2.7	3.5	1.1
2S02P2	4.6	12	2.2	4T02P2	4.7	6.2	2.2
2S03P7	6.9	18	3.7	4T03P7	6.9	9	3.7
2T05P5	9.5	25	5.5	4T05P5	8.5	13	5.5
2T07P5	12.8	33	7.5	4T07P5	14	18	7.5
2T0011	17.9	47	11	4T0011	18	27	11
2T0015	23	60	15	4T0015	24	34	15
2T18P5	29	75	18.5	4T18P5	29	41	18.5
2T0022	32	80	22	4T0022	34	48	22
